World Class
Distribution Transformers
A cast resin dry-type transformer (CRT) is a type of electrical transformer that uses solid epoxy resin insulation instead of oil or liquid coolant. It is designed for indoor and outdoor applications which offers high safety, low maintenance, and excellent resistance to moisture, dust, and pollutants.
A cast resin dry-type transformer is used in different commercial, industrial, and utility applications, as they come with various benefits. The advancements in this transformer have technologically made electrical devices efficient and compliant over the years.
Technical Specifications
| Range | Up to 5 MVA |
| Voltage Class | Up to 33 KV |
| Cooling | AN / AF |
| Protection | Up to IP 55 |
| Winding Material | Copper |
| Insulation Level | 'F' & 'H' Type |
| Tap Changer | On load Gears |
| Enclosure | Powder Coated |
Design Structure
Insulation Type
F and H class insulation are primarily used for the primary and secondary windings.
Lifespan
Depends on winding insulation integrity, which is affected by temperature rise due to overloading.
Core Material
Silicon steel is commonly used to ensure high permeability and minimal hysteresis loss.
Regulation
Achieved with a leakage resistance of less than 2% to maintain design efficiency.
Winding Material
Windings are made of copper or aluminium, depending on the current rating requirements.
Losses
To minimize eddy current and core losses, leakage and winding resistance must be controlled.
Overload
Leads to overheating, which limits loading capacity. A fan-cooling system is added to dry-type transformers to mitigate this issue.
Insulation Level
Selected based on the primary impulse level, contributing to the transformer's longevity.
K-Factor
Designed to withstand non-sinusoidal heat generation in the windings.
Witness Engineering
Excellence In Motion
Forestry
Used in remote forest locations.
Urban Substations
Installed in city substations.
Industrial Use
Essential for gas, oil, and chemical industries.
Harsh Environments
Operate in environmentally challenged areas.
Underground Systems
Found in underground substations.
Renewable Energy
Support renewable energy generation sites.
Key Benefits
Delivering dependable power with precision engineering, our transformers are built for maximum efficiency and long-term reliability.
Easy installation, low clearance
Strong overload support
Safe and eco-friendly
Reliable in moisture conditions
Cost-effective for fire protection
Short-circuit resistant
FAQs
How can industrial operations be made more efficient with power transformers?
Power transformers increase the efficiency of large-scale processes like manufacturing, chemical production, and power plants by ensuring steady voltage levels and lowering energy losses.
Lorem Ipsum passages, and more recently with desktop
Power transformers increase the efficiency of large-scale processes like manufacturing, chemical production, and power plants by ensuring steady voltage levels and lowering energy losses.
Lorem Ipsum passages, and more recently with desktop
Power transformers increase the efficiency of large-scale processes like manufacturing, chemical production, and power plants by ensuring steady voltage levels and lowering energy losses.
Lorem Ipsum passages, and more recently with desktop
Power transformers increase the efficiency of large-scale processes like manufacturing, chemical production, and power plants by ensuring steady voltage levels and lowering energy losses.
Lorem Ipsum passages, and more recently with desktop
Power transformers increase the efficiency of large-scale processes like manufacturing, chemical production, and power plants by ensuring steady voltage levels and lowering energy losses.
